ACCU-SCOPE® 3000-LED Upright Microscope
The ACCU-SCOPE® 3000-LED Microscope Series delivers outstanding optical performance, value and resolution to meet the exacting standards of life science professionals and students. With an Infinity Plan optical system, a best-in-class 20mm field of view, and a super-bright 3-watt LED illuminator, the 3000-LED Series provides high contrast images with outstanding resolution, precision design and enhanced illumination.
CONFIGURATION
3000-LED Microscope
-
Viewing Body: Binocular viewing head, inclined 30°, rotatable 360°
-
Eyepieces: HWF Plan 10x/20mm focusing eyepieces (paired - one w/pointer), with eyeguards
-
Nosepiece: Reversed quadruple nosepiece
-
Objectives: Infinity Plan achromat 4x, 10x, 40xR and 100xR oil objectives
-
Stage: Mechanical stage, 140 X 132mm
-
Condenser: Abbe condenser, N.A. 1.25 with iris diaphragm (with slot for sliders)
-
Focusing System: Coaxial coarse and fine focusing controls
-
Illumination: 3 watt LED variable illuminator
-
Accessories: Dust cover, power cord, immersion oil and instruction manual
KEY FEATURES
The newly redesigned infinity plan optical system provides high-resolution, high-contrast images that provide a flat image across the field of view. The long-lasting, 25,000+ hour LED illuminator provides a consistent color temperature across all specimen types.
Classroom Friendly. Lab Ready.
The 3000-LED Series is fully pre-assembled and ready to work when you remove it from its packaging. Built for both educational and laboratory environments, the 3000-LED maintains a small, stable footprint, an ergonomic carry handle, and a cast alloy aluminum frame that protects the focusing assembly when users move the microscopes to storage.
Ergonomically Designed
Designed for long periods of usage, the 3000-LED elegantly blends user controls with ergonomic features to make extended viewing periods comfortable. The coaxial focusing knobs are positioned low so a user can rest their hands on the counter while using the microscope. A low coaxial stage control allows the user to comfortably move the stage, and a variable illumination wheel allows the user to change the light intensity easily with the other hand. The viewing head is inclined at a comfortable 30-degree angle, and WF10x eyepieces allow for an ergonomically comfortable viewing position during extended observations.
Digital Imaging. Cameras. Monitors.
Built for imaging, the 3000-LED Series can easily connect with a wide range of our optional Excelis™ 4K, HD, USB and WiFi cameras to the microscope. It’s easy to connect our Excelis cameras to larger displays or HD projectors for classrooms and group discussions.
When combined with our ultra-compact 4K or HD monitors, the 3001-LED becomes a versatile, all-in-one solution allowing classrooms and laboratories to readily capture images without the need of a computer, saving precious space and budget!
Phase Contrast. Polarization. Darkfield.
Routine microscopy requires different contrast techniques, and the 3000-LED Series has options for slider phase contrast, polarization / gout analyzer and darkfield.
-
Viewing Body: Binocular or Trinocular (fixed 50:50 light split) Siedentopf type viewing head, inclined 30°; rotatable 360°; interpupillary distance adjustment 50-75mm
-
Optical System: Infinity optical system, f = 180mm, anti-mold
-
Objectives: Plan Achromat 2x, 4x, 10x, 20x, 40x*, 50x* oil, 60x*, 100x* water, 100x* oil; Plan Phase 10x, 20x, 40x*, 100x* oil *Spring-loaded
-
Eyepieces: HWF Plan 10x/20mm focusing eyepieces with roll down eyeguards (paired – one with pointer); eyepieces are locked-in to prevent classroom tampering; accepts optional 20.5mm reticle; Optional eyepieces include HWF10x/18mm, HWF10x/20mm non-focusing
-
Nosepiece: Rear facing quadruple, ball bearing nosepiece with positive click stops to ensure parcentration; optional quintuple nosepiece
-
Focusing System: Coaxial focusing system with adjustable tension control and upper limit stop to prevent accidental damage to slides; all metal gears, brass for fine focus gear
-
Stand: Cast aluminum alloy
-
Stage: Stage size 140mm x 132mm with X-Y movement range of 76mm x 50mm
-
Condenser: Abbe condenser NA 1.25 (with slot for sliders) with iris diaphragm
-
Illumination: 3 watt LED with variable intensity control; LED bulb is rated for over 25,000 hours of continued use; universal power supply 110-240v
-
Accessories: Dust cover, instruction manual included
-
Optional Accessories: Slider phase contrast set; darkfield slider (4x – 40x); field iris upgrade; simple polarizer/analyzer; gout kit; reticles; cameras and adapters; microscope carry case
-
Warranty: 5 year limited warranty for parts, labor, and electronic components; 1 year warranty on LED bulb
Brochures:
Dimensional Drawings:
Videos:
Manuals:
- 3000-LED Instruction Manual: VIEW PDF
- 3000-LED: Phase Slider Supplement: VIEW PDF
- 3000-LED: 2x Diffuser Slider Supplement: VIEW PDF
- 3000-LED: Simple Polarizer/Analyzer Installation: VIEW PDF
- 3000-LED: Gout Kit Installation: VIEW PDF
